Fields on the first setting block of this page:
Field Description
IP QoS Enable/disable the IP QoS function.
Source IP The IP address of the traffic source.
Source Netmask The source IP Netmask. This field is required if the source IP has been entered.
Destination IP The IP address of the traffic destination.
Destination Netmask
The destination IP Netmask. This field is required if the destination IP has been
entered.
Protocol
The selections are TCP, UDP, ICMP and the blank for none. This field is required if
the source port or destination port has been entered.
Source Port
The source port of the selected protocol. You cannot configure this field without
entering the protocol first.
Destination Port
The destination port of the selected protocol. You cannot configure this field
without entering the protocol first.
Physical Port
The incoming ports. The selections include LAN ports, wireless port, and the blank
for not applicable.
Fields on the second setting block of this page:
Field Description
Outbound Priority
The priority level for the traffic that matches this classification rule. The possible
selections are (in the descending priority): p0, p1, p2, p3.
IP Precedence
Select this field to mark the IP precedence bits in the packet that match this
classification rule.
IP Type of Service
Select this field to mark the IP TOS bits in the packet that match this classification
rule.
802.1p
Select this field to mark the 3-bit user-priority field in the 802.1p header of the
packet that matches this classification rule. Note that this 802.1p marking is
workable on a given PVC channel only if the VLAN tag is enabled in this PVC
channel.
