Fields in this page:
Field Description
Enable Port Forwarding Check this item to enable the port-forwarding feature.
Protocol There are 3 options available: TCP, UDP and Both.
Enable Check this item to enable this entry.
Local IP Address IP address of your local server that will be accessed by Internet.
Port
The destination port number that is made open for this application on
the LAN-side.
Remote IP Address
The source IP address from which the incoming traffic is allowed. Leave
blank for all.
External Port
The destination port number that is made open for this application on
the WAN-side
Interface
Select the WAN interface on which the port-forwarding rule is to be
applied.
Function buttons for the setting block:
Apply Changes
Click to save the rule entry to the configuration.
Function buttons for the Current Port Forwarding Table:
Delete Selected
Delete the selected port forwarding rules from the forwarding table. You can click
the checkbox at the Select column to select the forwarding rule.
Delete All
Delete all forwarding rules from the forwarding table.
