PROLiNK H5004N Wireless-N - Manual (Page 37)

PROLiNK ® H5004N User Manual www.prolink2u.com
Version 1.00 (Jan’10)
36
The IGMP Proxy page allows you to enable multicast on WAN and LAN interfaces. The
LAN interface is always served as downstream IGMP proxy, and you can configure one of
the available WAN interfaces as the upstream IGMP proxy.
Upstream: The interfaces that IGMP requests from hosts are sent to the multicast router.
Downstream: The interface data from the multicast router are sent to hosts in the
multicast group database.
Fields in this page:
Field Description
IGMP Proxy Enable/disable IGMP proxy feature
Proxy Interface The upstream WAN interface is selected here.
Function buttons in this page:
Apply Changes
Click to save the setting to the configuration.
Undo
Discard your settings.
