Agilent Technologies Z5623A Option H48 2 -3
Installation
Recommended Additional Equipment
Recommended Additional Equipment
The equipment listed in Table 2-2 is not shipped with the test set, but is
recommended for use with it. The remainder of this User’s and Service
Guide assumes that the user has the listed equipment (or its
equivalent) available.
Table 2-2 Recommended Equipment Not Supplied With Test Set
Description Model Or Part Number Quantity
PNA Series Network
Analyzer Agilent Model No.
E8356A, E8357A, or E8358A 1
Electronic Calibration
Module Agilent Part No. 85072-60007 1
Keyboard with USB
cable Hewlett-Packard Model No.
SK-2502U
a
1
Mouse with USB cable Hewlett-Packard Model No.
M-UB48
a
USB Quad Hub Peracom Model No.
UH4000A
a,b
1
USB Cable
Peracom Model No. CA2000A
a,b 1
RF Cable (24”)
Agilent Part No. 8120-4781
a 3
9/16” Wrench Agilent Part No. 8710-1770 1
3/4” Torque Wrench Agilent Part No. 8710-1766 1
Type N 50 Ohm Male
Short Agilent Part No. 85032-60016 2
Type N 50 Ohm Female
Short Agilent Part No. 85032-60015 2
Type N 50 Ohm Female
Termination Agilent Part No. 85032-60018 2
Type N 50 Ohm
Female-Female Adapter Agilent Part No. 85032-60021 1
a. Or equivalent
b. Available from Peracom Networks, Inc., Cary, North Carolina
(www.peracom.com).
