Agilent Technologies Z5623A Option H48 8 -7
Service
List of Replaceable Parts
List of Replaceable Parts
The following table contains the list of replaceable parts for the test set.
If any of these parts or assemblies is replaced, you must perform all
performance tests to verify conformance to specifications.
Table 8-1 Replaceable Parts for Z5623A Option H48
Reference
Designator
Description Part Number Quantity
A1 24 Volt Power
Supply
0950-2252 1
A4 2x16 LCD 2090-0370 1
Sw50-Sw57 1P2T Switch 26.5
GHz
33314C 8
W5 RF Cable 87050-20017 1
W9 RF Cable 87050-20024 1
J50-J57 CA AY 87050-60053 1
J10-J15 CA AY 87050-60055 6
A3 Driver PCB 87050-60324 1
Sw10-Sw15 1P4T Switch 26.5
GHz
87104C 6
Connector Type-N
(F)
86290-60005 10
W1 RF Cable Z5623-20027 8
W2 RF Cable Z5623-20028 1
W3 RF Cable Z5623-20029 1
W4 RF Cable Z5623-20030 1
W6 RF Cable Z5623-20031 1
W7 RF Cable Z5623-20032 1
W8 RF Cable Z5623-20033 1
W10 RF Cable Z5623-20034 1
W11 RF Cable Z5623-20035 1
W12 RF Cable Z5623-20036 1
W13 RF Cable Z5623-20037 1
W14 RF Cable Z5623-20038 1
