Agilent Technologies Z5623A Option H48 5 -35
Performance Verification
Setting Up Limit Testing
Turning On Limit Lines and Limit Testing
Step 1. Click Trace on the menu bar. When the Trace menu appears, scroll
down to the Limit Test... button and click it as shown in Figure 5-8 .
The Limit Test window shown in Figure 5-9 will pop up.
Step 2. Click the Limit Test ON and Limit Line ON boxes. The result is
shown in Figure 5-12 .
Step 3. Click the Hide Table button, then click the OK button.
Saving the Limit Test File
Step 1. Click File on the menu bar. When the File menu appears, scroll down to
the Save As... button and click it. See Figure 5-14 .
Step 2. When the Save As window comes up as shown in Figure 5-15 , enter a
file name. An appropriate file name for this step would be,
“crosstalk_with_no_cal”. After entering the file name, record it in
Table
5-3 on page 5-7 . Next, click the Save button in the Save As window.
Recalling the Limit Test File
Recall the limit test file that you have just saved. (Consult “ How to
Recall a Calibration ” on page 4-14 .) This will put it on the “Quick
Recall” list.
