88
Add TCP/UDP Filter
Field Description
Rule name
Users-define description to identify this entry or click “Select”
drop-down menu to select existing predefined rules. The
maximum name length is 32 characters.
Time Schedule
It is self-defined time period. You may specify a time schedule
for your prioritization policy. For setup and detail, refer to Time
Schedule section
Source/Destination
IP Address(es)
This is the Address-Filter used to allow or block traffic to/from
particular IP address(es). Selecting the Subnet Mask of the IP
address range you wish to allow/block the traffic to or form; set
IP address and Subnet Mask to 0.0.0.0 to inactive the Address-
Filter rule.
Type
It is the packet protocol type used by the application, select
TCP, UDP or both TCP/UDP.
Protocol Number Insert the port number
Source Port
This Port or Port Ranges defines the port allowed to be used by
the Remote/WAN to connect to the application. Default is set
