72
ADSL - Pure Bridge
Field Description
Profile Port Select the profile port either ADSL or 3G
Protocol The ATM protocol will be used in the device
Description A given name for the connection
VPI/VCI Enter the information provided by your ISP
ATM Class The Quality of Service for ATM layer
Encap Method
Choose whether you want the packets in WAN interface as
bridged packet or routed packet.
Acceptable Frame
Type
Specify which kind of traffic goes through this connection, all
traffic or only VLAN tagged.
Filter Type
Specify the type of ethernet filtering performed by the named
bridge interface:
• All: Allows all types of ethernet packets through the
port.
• IP: Allows only IP/ARP types of ethernet packets
through the port.
• PPPoE: Allows only PPPoE types of ethernet
packets through the port.
