29
land.com or with the compatibility list provided with the WebShare 244WN.
Field Description
Status
Show the status for 3G interface:
• 3G Card ready: Modem recognized, connection
unactive.
• Connect: Modem recognized, connection active.
• Closed: Modem recognized and disconnected after
ADSL connection failback.
• KO: Modem not compatible or fault.
Signal Strenght The signal strength bar indicates current 3G signal strength.
Network Name The network name that the device is connected to.
Card Name The name of the 3G card.
Card Firmware The current firmware for the 3G card.
Current TX/RX
Bytes
The statistics of transmission, count for this call.
Total TX/RX Bytes The statistics of transmission, count from system ready
