Atlantis Land WEBSHARE 3G 244WN - Manual (Page 15)

15
DSL
Connect the supplied RJ-11 (“telephone”) cable on this
port when connecting to the ADSL/telephone network.
Ethernet (1-4)
Connect a UTP Ethernet cable (Cat-5 or Cat-5e) to one of
the LAN ports when connecting to a PC or an office/home
network of 10Mbps, 100Mbps or 1000Mbps.
USB
Connect the USB cable on this port 3G/ HSDPA USB
modem backup for Internet access.
Console
Console port.
WPS
Push WPS button to trigger Wi-Fi Protected Setup
function.
Reset
To be sure the device is being turned on Æ press RESET
button for:
• 1-3 seconds: quick reset the device.
• 6 seconds above, and power off, power
on the device: restore to factory default
settings. (Cannot login to the router or forgot
your Username/Password. Press the button
for more than 6 seconds).
After pressing the RESET button for more than 6 seconds,
to be sure you power cycle the device again.
Power
Power ON/OFF switch
Power Switch
Connect the supplied power adapter to this jack.
