Internal expansion, 25 ton ram parts – Dixon Valve 25 TON RAM Complete Manual User Manual
Page 88
Die Holder
Internal Expanding Attachment
IX Adapter
IX Pull Rods
1 - 1 1/2"
IX Plug
2" & larger IX
Plug
Thrust Plates
Adapter Plate for Thrust Plate
Food Plug
Sanitary End Adapter
Acme Nut Adapter
IX Male NPT
Adapter
25 Ton Ram Parts -
Internal Expansion
These drawings represent the overall shape of the parts only. Please consult
the complete Ram Attachments listing for specific descriptions regarding
size, usage, etc.
