See page 23 for Interlocking Cam & Groove products.
Crimped Interlocking Cam & Groove Recommendation Guide
4" Interlocking Style Cam and Groove
Hose ID Ferrule Part #
Hose OD Crimp Diameter
(±0.005)
% Reduction Crimp Die # Offset
Fractional Decimal
4" CF400-1
CF400-2
CF400-3
CF400-4
CF400-5
CF400-6
CF400-7
CF400-8
CF400-9
CF400-10
4-23/64
4-24/64
4-25/64
4-26/64
4-27/64
4-28/64
4-29/64
4-30/64
4-31/64
4-32/64
4-33/64
4-34/64
4-35/64
4-36/64
4-37/64
4-38/64
4-39/64
4-40/64
4-41/64
4-42/64
4-43/64
4-44/64
4-45/64
4-46/64
4-47/64
4-48/64
4-49/64
4-50/64
4-51/64
4-52/64
4-53/64
4-54/64
4-55/64
4-56/64
4-57/64
4-58/64
4-59/64
4-60/64
4-61/64
4-62/64
4.359
4.375
4.391
4.406
4.422
4.438
4.453
4.469
4.484
4.500
4.516
4.531
4.547
4.563
4.578
4.594
4.609
4.625
4.641
4.656
4.672
4.688
4.703
4.719
4.734
4.750
4.766
4.781
4.797
4.813
4.828
4.844
4.859
4.875
4.891
4.906
4.922
4.938
4.953
4.969
4.553
4.565
4.578
4.590
4.603
4.615
4.628
4.640
4.653
4.665
4.678
4.690
4.703
4.715
4.728
4.740
4.753
4.765
4.778
4.790
4.803
4.815
4.828
4.840
4.853
4.865
4.878
4.890
4.903
4.915
4.928
4.940
4.953
4.965
4.978
4.990
5.003
5.015
5.028
5.040
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
20%
114
114
114
114
114
114
114
114
114
114
114
114
114
114
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
120
126
126
126
126
126
126
126
0.064
0.077
0.089
0.102
0.115
0.127
0.139
0.152
0.164
0.177
0.189
0.202
0.214
0.227
0.003
0.016
0.028
0.041
0.053
0.066
0.078
0.091
0.103
0.116
0.129
0.141
0.153
0.166
0.179
0.191
0.203
0.216
0.228
0.004
0.016
0.029
0.041
0.054
0.066
0.079
Note: The crimp die #'s and offset dimensions are for use with Dixon's Holedall Crimp System (CM400) only.
