Dixon Sanitary Style Crimp Stems
Sanitary End x Hose Shank
Female Bevel Seat End x Hose Shank
Female I-Line End x Hose Shank
Tube Weld End x Hose Shank
Size
316 Stainless Steel
Part #
1½"
2"
3"
4"
CILR150
CILR200
CILR300
CILR400
Size
316 Stainless Steel
Part #
1½"
2"
3"
4"
CTER150
CTER200
CTER300
CTER400
Size
316 Stainless Steel
Part #
1"
1½"
2"
3"
4"
CBSR100 1
CBSR150 1
CBSR200 1
CBSR300 2
CBSR400 1
1 only use with IXAN nut on page 14
2 only use with IXAN300 nut
Size
316 Stainless Steel
Part #
1"
1½"
2"
3"
4"
CSSR100
CSSR150
CSSR200
CSSR300
CSSR400
• sanitary style end
• Dixon sanitary crimp stems are only to be used with
Dixon stainless steel crimp ferrules
• reference pages 18-19 for crimp recommendations
• manufactured in AISI 304 stainless steel
• ferrules have a surface finish of 63 or better
Dixon Sanitary Crimp Ferrules
Hose
ID
Hose OD 304 stainless steel
from to Part #
1"
1½"
2"
1-26/64"
1-29/64"
1-32/64"
1-35/64"
1-38/64"
1-58/64"
1-62/64"
2-2/64"
2-6/64"
2-30/64"
2-34/64"
2-38/64"
2-42/64"
1-28/64"
1-31/64"
1-34/64"
1-37/64"
1-40/64"
1-61/64"
2-1/64"
2-5/64"
2-9/64"
2-33/64"
2-37/64"
2-41/64"
2-45/64"
F16G-1453
F16G-1500
F16G-1547
F16G-1594
F16G-1641
F24G-1969
F24G-2031
F24G-2094
F24G-2156
F32G-2531
F32G-2594
F32G-2656
F32G-2719
Hose
ID
Hose OD 304 stainless steel
from to Part #
3"
4"
3-39/64"
3-40/64"
3-44/64"
3-48/64"
3-52/64"
3-56/64"
4-40/64"
4-44/64"
4-48/64"
4-52/64"
4-56/64"
3-42/64"
3-43/64"
3-47/64"
3-51/64"
3-55/64"
3-59/64"
4-43/64"
4-47/64"
4-51/64"
4-55/64"
4-59/64"
F48G-3625
F48G-3688
F48G-3750
F48G-3813
F48G-3875
F48G-3938
F64G-4688
F64G-4750
F64G-4813
F64G-4875
F64G-4938
