Size
Hose OD 304 Stainless Steel
from to Part #
1½"
1½"
2"
2"
3"
3"
1-60/64"
2-4/64"
2-30/64"
2-42/64"
3-30/64"
3-47/64"
2-12/64"
2-22/64"
2-44/64"
2-54/64"
3-46/64"
3-54/64"
GAS2334NOS
GAS2370NOS
GAS2709NOS
GAS2885NOS
GAS3760NOS
GAS3885NOS
male adapter x
notched NOS hose shank
female coupler x
notched NOS hose shank
• For hose outside diameters of 2-4/64" and below, the couplings are crimp only.
• For hose outside diameters of 2-5/64" and above, the couplings can be crimped or swaged.
• See page 34 for male NPT notched NOS fittings.
Notched NOS Ferrules
crimped assembly swaged assembly
Contact the factory for swage
and crimp recommendations.
Dixon Notched NOS Shank Cam and Groove
Couplers
Adapters
swaged assembly crimped assembly
Contact the factory for swage
and crimp recommendations.
Size
316 Stainless Steel
Part #
1½"
2"
3"
150CNOSSS
200CNOSSS
300CNOSSS
Dixon type C
Size
316 Stainless Steel
Part #
1½"
2"
3"
150ENOSSS
200ENOSSS
300ENOSSS
type E
Only use the NOS shank with the NOS ferrules.
Due to differences in dimensions and tolerances for safety reasons, do not use other
manufacturer's stems or ferrules with Dixon Holedall products.
