Size
Carbon Steel
Part #
1¼"
1½"
2"
2½"
3"
4"
IXV20
IXV24
IXV32
IXV40
IXV48
IXV64
grooved end
Internal Expansion Stems
Butt Weld x Heavy Duty Raised End (California Style)
Clamps for IXH Raised End (California Style) Stems
Size
Carbon Steel
Part #
1"
1¼"
1½"
2"
2½"
3"
4"
6"
IXM16
IXM20
IXM24
IXM32
IXM40
IXM48
IXM64
IXM96
male pipe end
Size
Carbon Steel
Part #
1½"
2"
2½"
3"
4"
IXH24
IXH32
IXH40
IXH48
IXH64
heavy duty raised end
Beveled design for welding to Schedule 40 pipe allows connection to a heavy duty raised end (California style) hose fitting or
similar style end.
Length
Drop-forged steel clamps for fast assembly when connecting heavy-duty raised end fittings used for concrete. These clamps can
be used to connect the ends of pipes or hoses which use the Raised End or California style fittings listed above. Shipped with
double lipped gasket and safety pin. 1½" through 3" are galvanized; 4" and 5" are painted green. Clamp should only be used with
safety pin in place.
Size Length
Carbon Steel
Part #
1½"
2"
2½"
3"
4"
5"
1½"
1½"
1½"
1½"
1½"
1½"
HDE24
HDE32
HDE40
HDE48
HDE64
HDE80
California style end
Hose
ID
Forged Steel Clamps Buna-N Gaskets
Part # Part #
1½"
2"
2½"
3"
4"
5"
IXHC150
IXHC200
IXHC250
IXHC300
IXHC400
IXHC500
IXHCG150
IXHCG200
IXHCG250
IXHCG300
IXHCG400
IXHCG500
