External swaging, 25 ton ram parts – Dixon Valve 25 TON RAM Complete Manual User Manual
Page 87
Die Holder
Pusher Plate
Pusher Hat (4")
Pusher Adapter
Unirange Pusher
RSTXXX Spacer
Cam & Groove Space Ring 1 1/2" Cam & Groove Pusher 3" & 4" Cam & Groove
Pusher
2" Type C & E Cam & Groove Pusher;
3" Type C Cam & Groove Pusher
25 Ton Ram Parts -
External Swaging
These drawings represent the overall shape of the parts only. Please consult
the complete Ram Attachments listing for specific descriptions regarding
size, usage, etc.
