Global Air King Universal Couplings
Hose Ends
Size
Investment Cast Steel
Part #
1/2"
3/4"
1"
GAM1
GAM6
GAM11
Size
Ferrule
ID
Investment Cast Steel
Part #
1/2"
3/4"
1"
0.906
1.120
1.149
1.190
1.218
1.246
1.438
1.469
1.500
1.531
CCF0906
CCF1120
CCF1149
CCF1190
CCF1218
CCF1246
CCF1438
CCF1469
CCF1500
CCF1531
Air King is for air and water service only Warning: Never use any Air King coupling for steam service!
None of Dixon's catalog information is to be interpreted to mean that this type of coupling is suitable for use on steam hose.
½" Global Air King
Hose ID Stem Part # Ferrule Part #
Hose OD
Crimp Diameter
(±0.005)
% Reduction
Fractional Decimal
½" GAM1 CCF0906
CCF0906
CCF0906
54/64
55/64
56/64
0.8438
0.8594
0.8750
0.840
0.853
0.867
15
15
15
Hose ID Stem Part # Ferrule Part #
Hose OD
Crimp Diameter
(±0.005)
% Reduction
Fractional Decimal
¾" GAM6 CCF1120
CCF1120
CCF1149
CCF1149
CCF1190
CCF1190
CCF1218
CCF1218
CCF1246
CCF1246
1-5/64
1-6/64
1-7/64
1-8/64
1-9/64
1-10/64
1-11/64
1-12/64
1-13/64
1-14/64
1.0781
1.0938
1.1094
1.1250
1.1406
1.1563
1.1719
1.1875
1.2031
1.2188
1.082
1.094
1.107
1.119
1.122
1.134
1.147
1.159
1.182
1.194
20
20
20
20
20
20
20
20
20
20
¾" Global Air King
Hose ID Stem Part # Ferrule Part #
Hose OD
Crimp Diameter
(±0.005)
% Reduction
Fractional Decimal
1" GAM11 CCF1438
CCF1438
CCF1469
CCF1469
CCF1500
CCF1500
CCF1531
CCF1531
1-25/64
1-26/64
1-27/64
1-28/64
1-29/64
1-30/64
1-31/64
1-32/64
1.3906
1.4063
1.4219
1.4375
1.4531
1.4688
1.4844
1.5000
1.388
1.400
1.413
1.425
1.438
1.450
1.463
1.475
20
20
20
20
20
20
20
20
1" Global Air King
Air King Ferrules
Offers a low profile streamline appearance with maximum
retention.
• lightweight
• can be crimped
• ONLY to be used with the global air kig hose end,
shown above
Crimped Air King Recommendation Guide
29 877.963.4966 • www.dixonvalve.com
