Wiring Diagram
ITEM
PART NO.
QTY.
DESCRIPTION
1
2801306
1
Control Panel Harness
2
2800429
1
Engine Harness
3
2800397
1
Tach Sensor Harness
4
2800392
1
Relay Harness
5
2800393
1
Hydraulic Pump Harness
6
2800600
1
Battery, 12V
7
2800565
1
Battery Disconnect Switch
8
6079077
1
Cable, Battery (POS) to Disconnect
9
6079080
1
Cable, Battery (NEG) to Ground
10
6079078
1
Cable, Disconnect to Lift Pump
11
6079079
1
Cable, Disconnect to Starter
12
2600070
1
Hydraulic Pump Unit
13
2700169
1
Solenoid, Motor
14
2800372
1
Pushbutton Switch, Raise
15
2800373
1
Pushbutton Switch, Lower
16
2801474
2
Switch, N.O. Pushbutton
17
6010416
1
Tach/Hour Meter (VDO) Calibrated
2800611
2
(Light Socket)
2800612
2
(Light Bulb, Wedge Base)
18
2800169
1
Magnetic Sensor
19
2800387
1
Circuit Breaker, 25A
2800364
1
Circuit Breaker Boot, Red
20
2703194
1
Ignition Switch & Key
2703195
1
(Ignition Key Only)
21
2800144
1
Relay, Ignition
22
2801367
1
Emergency Stop Button
23
2702274
1
Starting Motor (Includes #24)
24
2701823
1
Solenoid Switch
25
2800144
1
Relay, Water Safety Switch
2800263
1
Relay Connector
2800264
4
Wire Terminal, 1/4" Push-on
26
2800062
1
Toggle Switch
2800063
1
Boot, Toggle Switch
27
2800060
1
Water Pressure Safety Switch
28
2800388
1
Fuse Panel, 6 Circuit
2800389
2
Fuse, 10A Red ATO/ATC
29
2703192
1
Temperature Gauge, Pricol
30
2700785
1
Alternator Light
2700293
1
(Bulb Only)
31
2800787
1
Oil Temperature Light
2700293
1
(Bulb Only)
31
2800786
1
Oil Pressure Light
2700293
1
(Bulb Only)
