Index
Serial Tags
Saw Serial Tag
The saw’s serial tag is located on the left side of the dash. Record this number below for future reference and
customer service purposes.
Serial Number
Engine Serial Tag
The engines serial tag is located on the top of the engine attached to the valve cover. Record this serial tags
model and serial number below for future reference and customer service purposes.
Model Number
Serial Number
Troubleshooting
Troubleshooting
Symptom
Problem
Solution
Engine will not start.
Emergency stop button activated?
Pull out on emergency stop button.
Out of fuel?
Check for fuel in tank.
Fuel filter or lines clogged?
Replace fuel filter or lines.
Weak or worn out battery?
Test, charge, or replace battery.
Faulty battery connection?
Inspect, clean and tighten battery cables.
Main circuit breaker tripped?
Check wiring for short.
Cold weather condition?
Pre-Heat engine with glow plugs.
Engine Malfunction?
Refer to Deutz manual.
Saw will not rise.
Defective solenoid start switch?
Check and replace hydraulic pump solenoid.
Worn out battery?
Test, charge, or replace battery.
Defective raise button?
Check and replace raise button.
Saw Will Not Lower.
Debris in lowering valve stem?
Remove, inspect, and clean valve stem.
Worn out battery?
Test, charge, or replace battery.
Defective lowering button?
Check and replace lowering button.
Saw lowers to fast/slow.
Improper lowering speed?
Adjust flow valve knob on hydraulic pump.
Saw will not completely lower.
Depth stop set?
Turn the knob on the depth stop counterclockwise.
Machine not cutting straight.
Misaligned rear axle?
Adjust rear axle alignment.
Excessive force applied when sawing? Reduce forward speed.
Wrong blade for application?
Contact dealer or manufacturer for correct blade.
Short Belt Life
Loose belts causing slippage?
Check belt tension on regular basis.
Sheaves misaligned?
Use straightedge to check alignment.
Worn sheave grooves?
Check for groove wear and replace as necessary.
Mismatched belt set?
Replace with new set of belts, DO NOT mix new and old.
Overheating PTO?
Check belt tension and lubricate PTO every 25 hrs.
References
1. Deutz AG
• Operations Manual 2011, 1
st
Edition, Germany 2008
• Spare Parts Catalogue D/TD/TCCD 2011, 1
st
Edition, Germany, 2008
2. Diamond Products
• CG-2 Mini Groover/Grinder With 49 HP Diesel Manual, Grand Rapids, 2012
25
