32
Maintenance and Care
5.4.2 Attaching the Power Pack
Please read the safety information in
Chapter 1.
1. Switch off the Port A Scrub using the
main switch (Fig. 14/1).
2. Pull the Port A Scrub against the
Power Pack (Fig. 14/2).
3. Tip the machine to the rear until the
Power Pack can be installed on the
holder (Fig. 14/3).
4. Tip the machine forward again so
that it is horizontal on the floor. The
Power Pack now hangs in the hold-
er.
5. Slide the safety catch (Fig. 14/4) up-
wards. Plug the battery plug (Fig. 14/
5) in the socket on the Port A Scrub.
5.4.3 Detaching the Power Pack
The Power Pack is detached in the re-
verse sequence to which it was in-
stalled on the Port A Scrub.
Fig.14
2
1
3
4
5
