16
Operation
3.1.3 Solution tank
The solution tank (Fig. 7/1) for the Port
A Scrub is located under the housing
cover (Fig. 7/2) and has a capacity of
approx. 10 liters. The solution supply is
activated by a button and flows at a rate
of approx. 0.22 liters/min.
3.1.4 Recovery tank
The waste water which is vacuumed up
is fed via a suction hose from the
squeegee to the recovery tank (Fig. 7/
3).
3.1.5 Power Pack
The Power Pack (Fig. 7/4) is equipped
with maintenance-free batteries, a fully
automatic battery charger and a total
discharge signal transducer (TSG) to
protect against total discharge. Pay at-
tention to the safety information with re-
gard to this.
For information on driving batteries, re-
fer to Supplementary Sheet 88-10-
2556.
Fig.7
3
1
4
2
