Starting Up
2 Starting Up
2.1 Prior to starting up for the
first time
1. Open the box containing the Port A
Scrub at the bottom and pull up-
wards. Loosen the plastic bands and
remove the machine carefully from
the pallet.
2. Remove the insulation blocks (Fig. 2/
1).
3. Loosen the adjusting knob (Fig. 2/2)
and move the steering shaft to its op-
erating position (guide marks facing
each other). Screw the adjusting
knob tight again.
4. Remove the Power Pack (Fig. 2/3)
from the packaging.
Before starting up the equip-
ment for the first time, you
must fully charge the batteries
to be used by completing the
initial battery charge routine
properly, refer to Section 5.4.1.
Minuteman is not deemed lia-
ble for damage to the battery
resulting from failure to com-
plete the initial battery charge
properly.
Fig.2
1 1
2
1 1 3
