23
Operation
3.3.2 Troubleshooting
Following poor cleaning results:
• Check the air intake filter (Fig. 12/1)
for blockages.
• Check the sealing (Fig. 12/2) of the
recovery tank.
• Check the suction hose and squee-
gee in the brush head (Fig. 12/3) for
blockages.
• Empty the recovery tank (Fig. 12/4).
3.3.3 Transport and loading
1. Detach the Power Pack, refer to
Section 5.4.3.
2. Only transport the Power Pack in a
vertical position, protecting it from
tipping and rolling away.
3. Loosen the adjusting knob (Fig. 12/
5) and move the shaft to its trans-
porting position.
4. Remove the brushes and set the
supporting rollers to their working
position. Lash the machine housing
to the transportation device with ap-
propriate load fixation devices (Fig.
12/6).
Fig.12
5
4
3
2
1
6
