15
Operation
3 Operation
3.1 Method of operation
General information
The Port A Scrub is a scrubber drier for
wet cleaning hard floors.
3.1.1 Brush head
The rotating brushes in the brush head
(Fig. 6/1) scrub the dirt free, thoroughly,
with a solution and clean the floor. The
brushes can be disassembled for main-
tenance purposes.
3.1.2 Squeegee
The moving, suspended squeegee (Fig.
6/2) is adjusted for forward and reverse
operation by means of a hand lever.
The sealing strips on the squeegee
adapt perfectly to the floor. A suction
turbine vacuums up the dirty solution
from the floor.
Fig.6
1
2 2
