MOD 30ML Multiloop Controller
MECHANICAL INSTALLATION
20
MOUNTING DIMENSIONS FOR SLC RETROPAK
Center-to-Center
Distance
F G
Recommended 4
8
Minimum 3.5
7
Inches mm
Inches mm
0.60 15.2
5.43
137.9
0.87 22.1
5.47
138.9
1.13 28.7
5.69
144.5
2.69 68.3
7.00
177.8
2.87 72.9
8.00
203.2
3.50 88.9 15.75
400.0
4.00 101.6
1.5 inch (38.1mm) clearance for optional communications jack.
NOTES: 1. When mounting housing in panel cutout or rack and panel mounted bezel, turn retaining screws
until point of screw touches rear of panel or bezel. Overtightening of retaining screws will
distort housing. Housing must be square after retaining screws are tightened.
Figure 2-2 Controller Mounting Dimensions
