Micromod MOD: Remote I/O Modules for use with 2020N Remote I/O Interface Module - Manual (Page 31)

Remote I/O Modules
ELECTRICAL CONNECTIONS
3.6.7 ICSO 08 Y1: 8 Transistor Outputs 24Vdc 2A
Binary output unit with 8 transistor output channels 24 VDC 2A. The unit has to be mounted
on a plug-in base ECZ.
Description:
Eight yellow input status led's
«0» to «7» .............1
«TEST» push-button 2
Red error led ........3
List of error codes 4
Electrical Connection:
Connect 24VDC as shown.
3 2 4
ICSO08Y1 24 VC
I/O REMOTE UNIT ABB Procontic CS 31
Unit error
Bus error TEST
0
1
2
3
4
5
6
7
1 2 3
1
4 5 6 7 0
Unit error
Overload
Short circuit
Shield
Bus # 1
Bus # 2
A
Common +
Common +
B
C
D
E
F
G
Common -
A
B
C
H
Load
H
G
Load
Load
Load
Load
Load
Load
Load
F
E
D
27
