53ML5100B Manual Loader
INSTRUCTION MANUAL

1.3 Specifications

Item

Specification(s)

Power

Range (as specified in model number)

22 - 26 V dc
108 - 132 V rms
216 - 264 V rms
50/60 Hz

Power Consumption (ac/dc operation)

36 VA maximum

Internal Power Supply:
Available Power Output for Transmitters

25 V dc ± 1 V dc @ 80 mA maximum, short circuit protected.

Output Ripple

200 mV p-p maximum

Analog Input (ANI0 & 1) Signals (all analog in-puts are referenced to signal common)

Quantity

2 (ANI0 & ANI1)

Signal Range

0 -5 V dc or 1 -5 V dc (0 -20 mA and 4 -20 mA dc respectively).

NOTE: The rear terminal board has the appropriate resistors for

ANI0 and ANI1.

Input Impedance

1 megohm minimum for voltage inputs; value of ranging resistor for
current signals.

Measurement Accuracy

± 0.1% of span

Analog Output (ANO0) Signal (is referenced to power common)

Quantity

1 (ANO0)

Signal Range

0 -20 mA dc (4 -20 mA dc typically)

Load Range

0 - 750 ohms

Accuracy

± 0.2% of span

Sampling and Update Attributes

Program Scan Rate

0.05 seconds

Analog Input Signal Sampling Rate

0.05 seconds

Contact Input Signal Sampling Rate

0.05 seconds

Display Update

0.10 seconds

Output Signal Update

0.05 seconds


7
