Page 35

Pg 35

ENTER

6.4.20
SERIAL USAGE

SERIAL USAGE

SERIAL HARDWARE
RS232 RS485

DEVICE ID

BAUD RATE
300 600 1200

BAUD RATE
2400 4800 9600 19200

PARITY
None Odd Even

HANDSHAKING
None Softwre Hardwre

DEVICE LINE FEED

MODEM OPTIONS
No Yes

MODEM INIT MASTER
No Yes

MODEM AUTO ANSWER
No Yes

CALL OUT PHONE #

CALL OUT TIME

##:##:##

Continued on Next Page

Press Enter to begin setup of the Serial Port.

Select Serial Hardware type for standard port.

Select the Device ID.

Select the desired Baud Rate.

(If selected)

Select the desired Parity.

Set the Handshake.

Choose end of line termination. Only choose if
your external device automatically assigns a line feed for
every carriage return.

Select "Yes" if the serial port will be used to control a
modem.

Select "Yes" to have the unit engage in a configuration
conversation with the modem on power up .

Select the desired Modem Auto Answer mode.

Enter the Call Out Phone Number to be dialed for "Call
Out Time" or "Print On Error/Alarm".

Enter the time of day to perform Call Out transmission.
