INSTRUCTION MANUAL
276-5XX SERIES 4-20MA TRANSMITTERS
276-515 4 Phase (210 Meters) Amphenol
276-525 4 Phase (210 Meters) Weather-Tight, Explosion proof (UL, CSA)
276-517 7 Phase (220/240 Meters) Amphenol
276-527 7 Phase (220/240 Meters) Weather-Tight, Explosion proof (UL, CSA)
TABLE OF CONTENTS
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg 2
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg 3
Installation:
Mounting / Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg 4
Moisture Protection / Temperature Considerations . . . . . . . . .Pg 5
Grounding / Typical Wiring Schematics . . . . . . . . . . . . . . . . .Pg 6
User Options & Adjustments:
Zero and Span Adjustments . . . . . . . . . . . . . . . . . . . . . . . . . .Pg 7
Damping / Over Range Indication . . . . . . . . . . . . . . . . . . . . .Pg 8
PCA Drawings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Pg 9
Ripple Adjustment (276-515 and 276-525) . . . . . . . . . . . . . .Pg 10
General Considerations:
Response Rate, Accuracy & Noise . . . . . . . . . . . . . . . . . . . . .Pg 11
Schematics:
D276-515-200
D276-517-200
276-515-350 © 2006, Max Machinery, Inc.
Max Machinery, Inc. reserves the right to make changes to the product in this Instruction
Manual to improve performance, reliability, or manufacturability. Consequently, contact
MMI for the latest available specifications and performance data.
Although every effort has been made to ensure accuracy of the information contained in
this Instruction Manual, MMI assumes no responsibility for inadvertent errors.
Discontinued
