Max Machinery 121 INDICATOR - Manual (Page 30)

Pg 30 121-000-350 © 2001 Max Machinery, Inc.
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
ENTER
6.4.12
SET FLUID
PROPERTIES
6.4.13
SETUP
PULSE OUTPUT
SET FLUID PROPERTIES
REF. DENSITY
###### lbs/g
REF. TEMPERATURE
###### F
EXPAN. FACTOR [xe-6]
########
CALIBRATION DENSITY
########
VISCOSITY COEF. A
0.000
VISCOSITY COEF. B
0.000
BASE DENSITY H2O@4C
###### lbs/g
Advance To
SETUP Pulse OUTPUT
SETUP PULSE OUTPUT
PULSE OUTPUT USAGE
Off Vol CVol/Mass
PULSE WIDTH
10mS 100mS
PULSE VALUE
####### gal/P
Advance To
SETUP ANALOG OUTPUT
Press ENTER at this prompt to Set Fluid Properties.
Enter the Reference Density. This is used in the calcula-
tion of density when you have a temp transmitter and
used for corrected flow calculation if you have a density
transmitter.
Enter the Reference Temperature.
Enter the proper Expansion Factor.
(If Temp Compensated for Mass or Corrected Volume)
See Section 7.4, Calculating the Expansion Factor.
Enter the Calibration Density. This is used in calculation
of flow for analog inputs using SQRT.
Not applicable for P.0 meters
Not applicable for P.0 meters
Enter the Base Density H2O@4C. This is used in the
centistoke calculation for UVC.
Press ENTER at this prompt to setup the Pulse Output.
Select the desired Pulse Output Usage.
Select the desired Pulse Width for the Pulse Output.
Enter the desired Pulse Value for the Pulse Output (Units
per Pulse).
