Max Machinery 121 INDICATOR User Manual

Page 27

Pg 27

SETUP
FLOW INPUT

(Pulse - Quadrature,
Qx1 or Qx2)

NOTE:

Ain = Single Pulse
PS(A=B) = Pulse

Security

Qx1 = Quadrature
Qx2 = Quadrature x 2

Select the desired Excitation Voltage.

Press ENTER when Pulse is flashing to configure the
flow input for Pulse signals.

Enter the desired Pulse type. See side note.

Select the desired Input Pulse Trigger Level.

Select the desired Low Pass Filter.
(Max. Count Speed).

Select the proper input termination.

Enter the desired Maximum Sample Window Time (1-999
in 1/10 sec increments).

Enter the desired K-Factor Type.

If Avg selected, Enter the desired Average K-Factor (KA
for channel A).

Enter the desired Average K-Factor (KB for channel B).

If LinTbl selected,
Enter the desired frequency/ K-Factor pair for each point
in the Linearization Table. (channel A)

NOTE: Enter 0 for Fre value of any point

(other than Fre01) to exit the routine
and use the values entered up to that point.

Enter the desired frequency/ K-Factor pair for each point
in the Linearization Table. (channel B)

NOTE: Enter 0 for Fre value of any point (other than
Fre01) to exit the routine and use the values entered up
to that point.

Enter the desired volumetric Low Rate Alarm.
This will trigger an alarm message if alarm conditions
occur. The relays are not affected.

Enter the desired volumetric High Rate Alarm.
This will trigger an alarm message if alarm conditions
occur. The relays are not affected.

EXCITATION VOLTAGE
5v 12v 24v

FLOW INPUT TYPE
Pulse Analog

PULSE INPUT TYPE
Ain PS(A=B) Qx1 Qx2

PULSE TRIGGER LEVEL
10mV 100mV 2.5V

LOW PASS FILTER
40Hz 3KHz 20KHz

INPUT TERMINATION
Pullup Pulldown None

MAX WINDOW (1-999) 1/10 sec.

K_FACTOR TYPE
Avg LinTbl UVC

AVERAGE KA-FACTOR
####### P/gal

AVERAGE KB-FACTOR
####### P/gal

LINEAR TABLE KA
Fre01:######## Hz

LINEAR TABLE KA
KA--01:####### P/gal

LINEAR TABLE KB
Fre01:######## Hz

LINEAR TABLE KB
KA--01:####### P/gal

LOW FLOW RATE ALARM

####### gal/m

HIGH FLOW RATE ALARM
####### gal/m

Advance To

SETUP AUX INPUTS
