6.2 EZ Setup
The EZ Setup routine is a quick and easy way to configure the unit for the most commonly used instrument
functions. This setup assumes that you are measuring Volumetric Flow. Entering the EZ Setup mode
automatically sets many features. This may cause any previously programmed information to be lost or reset.
For a complete customized configuration, see sections 6.3 and 6.4.
121-000-350 © 2001 Max Machinery, Inc. Pg 21
Select Setup to enter the instrument setup rou-
tine.
Press ENTER to begin EZ Setup routine.
Confirm that you want to run EZ Setup. Caution:
Any previous program settings may be lost or
reset.
Instrument Type.
Select the appropriate rate time base.
Enter the desired rate decimal location.
0-3 decimal places allowed.
Enter the desired totalizer units label.
Enter the desired totalizer decimal location. 0-3
decimal places allowed.
Enter the desired K-Factor Type.
If Average selected, Enter the desired Average K-
Factor.
If LinTbl or UVC selected,
Enter the desired frequency/ K-Factor pair for
each point in the Linearization Table. (up to 16 pairs)
Enter a frequency of 0 for any point other than
Fre01 to exit Linearization Table setup.
Enter the desired full scale setting for the analog
output.
Return to Run Mode
6.2.1
TOP LEVEL
SETUP MENU
6.2.2
EZ Setup
Submenu
Groups
SELECT OPERATE STATE
Run Setup Test
SELECT EZ SETUP
ARE YOU SURE?
No Yes
INSTRUMENT TYPE
Rate/Tot Batch
RATE time base
Sec Min Hour Day
RATE Dec places
0
TOTAL VOLUME UNITS
gal
TOTAL Dec places
0
K_FACTOR TYPE
Avg LinTbl UVC
AVERAGE KA-FACTOR
####### P/gal
LINEAR TABLE KA
Fre01:######## Hz
LINEAR TABLE KA
KA--01:##########
FS ANALOG OUT 20mA
#######gal/m
RATE 00.0 gal/m
TOTAL
0 gal
