MAP Technology

Maintenance and Cleaning

PN 89-00002-00-013 Rev. D

4 - 5

Reinstall the Air Filter

‹

To reinstall the air filter:

1. Install the air filter and lift into position and place the two spring

clamp flaps.

2. Reinstall the Luminex 100E analyzer front panel.

Syringe

Remove and replace the syringe every six months.

Remove the Syringe

When removing the syringe and the air filter, you must remove the
front panel of the Luminex 100E analyzer. See “Luminex 100E
Analyzer Front Panel” on page 4-4 for more details.

‹

To remove and replace the syringe:

1. Perform the decontamination procedure. See “Decontaminating

the Luminex 100E Analyzer for Return Shipment” on page 2-6
for details.

2. Turn off the Luminex 100E analyzer, but make sure the Luminex

100E analyzer is connected to protective ground. Wear a ground
strap.

3. Remove the front panel from the Luminex 100E analyzer. See

“Luminex 100E Analyzer Front Panel” on page 4-4 for more
information.

4. Remove the air filter.

5. Loosen the thumb screw on the bottom of the syringe arm.

6. Lower the syringe arm completely.

7. Unscrew the syringe from the pump head.

8. Remove the syringe.

Replace the Syringe

‹

To replace the syringe:

Note: Ensure that the Luminex 100E analyzer is powered off prior to
replacing the syringe.

1. Screw the new syringe into the syringe head.

2. Lift the syringe arm up to the bottom of the syringe.

3. Tighten the thumb screw.
