Luminex 100E User Manual

x

MAP Technology

4 - 4

PN 89-00002-00-013 Rev. D

As Required

Luminex 100E Analyzer
Front Panel

To access many of the analyzer’s components for periodic
maintenance, you must first remove the front panel. Additionally,
you may need to remove the air filter located behind the analyzer’s
front panel.

Remove the Luminex

100E Analyzer Front

Panel

‹

To remove the Luminex 100E analyzer front panel:

1. Remove the six button-head screws and washers.

2. Lift out the Luminex 100E analyzer front panel.

Reinstall the Luminex

100E Analyzer Front

Panel

‹

To reinstall the Luminex 100E analyzer front panel:

1. Install the front panel with louvers facing down and out, and

align it with the six screw holes.

2. Install the six washers and button-head screws.

Air Filter

Remove and replace the air filter as necessary.

Periodically, you may need to clean the air filter for optimal Luminex
100E analyzer performance. To clean the air filter, you must first
remove it from the Luminex 100E analyzer. Do not run samples
when the air filter is not in place. Clean the air filter as necessary.

Remove the Air Filter

‹

To remove the air filter:

1. Remove the front panel from the Luminex 100E analyzer.

2. Remove the two spring clamp flaps from each side of the filter

and lift out the air filter.

Clean the Air Filter

‹

To clean the air filter:

1. Remove the air filter.

2. Clean the filter with a vacuum or by placing it under running

distilled water.

3. Stand the air filter up to air dry.

4. Reinstall the air filter.
