Luminex 100E User Manual

x

MAP Technology

3 - 12

PN 89-00002-00-013 Rev. D

Installing the

Luminex 100E

Analyzer into the

Host System

The Luminex 100E analyzer has three electrical and four fluid
connectors that interface to the host system:

P1 Communications Port

P2

Synchronization Port

Power input connector

Sample Input Tube

Nonpressurized Sheath Fluid Connector

Waste Fluid Connector

Pressurized Sheath Fluid Connector

‹

To install the Luminex 100E analyzer into the host system:

1. Connect the USB communications cable from the host system to

the P1 communications port (DB9) on the Luminex 100E
analyzer.

2. Connect the synchronization cable from the host system to the

P2 Synchronization Port (DB15) on the Luminex 100E analyzer.

3. Connect the nonpressurized sheath, waste, and pressurized

sheath fluid lines from the host system into the color-coordinated
connectors at the lower left of the sample input tube on the
Luminex 100E analyzer. The connectors snap into the injection
port using firm pressure.

4. Remove the white cap covering the sample input tube and

connect it to the sample aspiration interface from the host
system.

5. Remove the yellow cap covering the power input connector and

connect the power source from within the host system to the
power input connector (21-pin cylindrical connector) on the
Luminex 100E analyzer.

6. Place the Luminex 100E analyzer into the host system.

Note:

Due to the weight, use

two people to lift the Luminex
100E analyzer.
