MAP Technology

Luminex 100E Analyzer Overview

PN 89-00002-00-013 Rev. D

3 - 9

Table 2 lists the P2 synchronization port pinouts.

Table 2: P2 Synchronization Port Pinout

Pin Number

voltages

Description

Pin 1

None

Unused

Pin 2

None

Input 1 return

Pin 3

Unloaded, maximum voltage of
5.25 volts

Spare input

Pin 4

None

Unused

Pin 5

None

Output 1 return

Pin 6

No voltage originates from the
Luminex 100E analyzer at this
pin

Output 2

Pin 7

None

Unused

Pin 8

None

Spare output
return

Pin 9

Unloaded, maximum voltage of
5.25 volts

Input 1

Pin 10

None

Unused

Pin 11

None

Spare input
return

Pin 12

No voltage originates from the
Luminex 100E analyzer at this
pin

Output 1

Pin 13

None

Unused

Pin 14

None

Output 2 return

Pin 15

No voltage originates from the
Luminex 100E analyzer at this
pin

Spare output
