Luminex 100E User Manual

x

MAP Technology

3 - 8

PN 89-00002-00-013 Rev. D

The P1 Communications Port is a nine-pin DB female-style
connector for communication between the P1 port and the host
computing and control system.

Table 1 lists the P1 communications port pinouts.

P2 Synchronization

Port (DB15-PIN)

The P2 Synchronization Port is a digital I/O port that provides one
input line and two output lines. The P2 synchronization port is used
to connect the Luminex 100E analyzer and the host computing and
control system. Refer to “P2 Synchronization Port Pinout” on
page 3-9 to see the P2 synchronization port.

The P2 Synchronization Port is a 15-pin DB female style connector
to allow communication between the Luminex 100E analyzer and the
host computing and control system.

The Luminex 100E analyzer uses open collector outputs; the inputs
are designed to interface with open collector outputs from the host
system.

Table 1: P1 Communications Port Pinout

Pin Number

voltages

Description

Pin 1

None

USB D-

Pin 2

Maximum of 5.25

Reserved

Pin 3

No voltage originates from the
Luminex 100E analyzer at this
pin

Reserved

Pin 4

None

No connect

Pin 5

None

Chassis
ground

Pin 6

Maximum of 5.25

USB D+

Pin 7

None

No connect

Pin 8

None

USB ground

Pin 9

No voltage originates from the
Luminex 100E analyzer at this
pin

USB Vbus
