MAGNUM VENUS PLASTECH Innovator Megaject Manual 15
Innovator Megaject
GETTING STARTED
The Innovator Megaject uses the Patriot pumping system for accurate metering.
This manual provides information needed to properly operate and perform simple
maintenance and repair on this equipment.
Step-by-step operations procedures are provided.
This manual includes Installation, Start-up and Shut-Down instructions.
Step-by-step assembly and disassembly procedures are included for
each component.
Please read this manual carefully. Follow the steps in the order given, otherwise
you may damage the equipment or injure yourself.
Component Assemblies:
The Innovator Megaject consists of a number of components – these
components will have their own detailed manuals and drawings. For complete
repair and maintenance instruction please reference these manual.
Megaject Dispense Head
Innovator Megaject 3250: (8000)
Patriot Powerhead Manual – PAT-PH-3250
Patriot 1-1/4 Fluid Section Manual – PAT-LS-12270-PE
Patriot Metering Pump Manual – PAT-CP-0550
Innovator Megaject 5000: (8001)
Patriot Powerhead Manual – PAT-PH-5000
Patriot 1-3/4 Fluid Section Manual – PAT-LS-24050-PE
Patriot Metering Pump Manual – PAT-CP-0980
SECTION
1
