FLAGS INTERPRETATION
FLAG DESCRIPTION
Alarm max/min activated
!
- Interruption coils circuit
- Signal error
- Empty pipe
C Calibration running
S Simulation
Pulse output saturation (reduce
TIME PULSE)
FLAGS AND LED INTERPRETATION
FLAGS
LED
LED INTERPRETATION
PERMANENT LIGHT: initialization
FLASHING LIGHT ( 1 sec.): normal function
FLASHING LIGHT (<1 SEC.): alarm on
The LED signals the real alarm status only if the display visualizes
one of the visualization pages
