Wiring Tables

This appendix provides a tabular description of the wiring connections made to each LCR-II terminal block. It should

be referenced in the event wiring is inadvertently mis-routed in the field, or for general troubleshooting in the event of

a problem.

Jumper J10 on LCR-II circuit board must be set for RS-232

communication protocol.
* For a standard RS-232 terminal (other than the Lap Pad), the

red wire is connected to J3-47.

Jumper J10 on LCR circuit board must be set for RS-485

communication protocol.

The drain wire must be connected to Pin 13 of terminal J6 in the

LCR-II. It must not be connected in the cab. Trim the drain wire

from the cable end in the cab.
The LCR-II Power cable kit includes a fuse holder and fuse to

protect the system in the event of a short circuit in the cable.

Liquid Controls recommends that this fuse be used in all

installations not having a fused accessory block to protect the truck

in the event of cable faults.

PRInTeR ConneCTIon (j1)

Terminal Pin

signal

Wire Color Cable

#81513

Route To

J1-30

GND

Black

Printer, Pin 7

29

CTS

Blue

Printer, Pin 20

28

RXD

Yellow

Printer, Pin 2

27

TXD

Orange

Printer, Pin 3

26

RTS

Brown

Printer, Pin 6

PoWeR ConneCTIon (j6)

Terminal Pin

signal

Wire Color

Route To

J6-13

Earth

Drain/Green Wire

No Connection

12

GND

Black

DC Ground

11

+12V In or

+24V In

Red

+12VDC or

+24VDC

PRInTeR ConneCTIon (j1)

Terminal

Pin

signal

Wire Color

Cable #81513

Route To

J3-51

GND

White

Ground, Pin 5

50

CTS

Green

RTS Terminal, Pin 4

49

RXD

Gray

TXD Terminal, Pin 3

48

TXD

Violet

TXD Terminal, Pin 2

47

RTS

*

CTS Terminal, Pin 8

46

+Vo

Red

Lap Pad +12, Pin 8

fRonT CoveR PUsh bUTTons &

InTeRnal PUlseR ConneCTIon (j8)

Terminal

Pin

signal

Wire Color

Cable #81513

Route To

J8-38

GND

Black

Internal Pulser GND

37

GND

Black

Push Button GND

36

In 1

Violet

INCREASE Button

35

In 2

Gray

SELECT Button

34

In 3

Green

Int. Pulser “B”

33

In 4

White

Int. Pulser “A”

32

+5V Out

Red

Int. Pulser “+”

31

+Vo

lIQUId ConTRols Pod (j8)

Terminal

Pin

signal

Wire Color

Cable #81513

Route To

J8-38

37

GND

Black

Pulser Signal GND

36
35
34

In 3

Green

Channel B Output

33

In 4

White

Channel A Output

32
31

+Vo

Red

+V Input

TeRMInal ConneCTIon Rs-485 (j2)

Terminal

Pin

signal

Wire Color

Route

To

Cable #81572 Cable #81513

J2-25

485-B

Black

Violet

Terminal

24

485+A

Red

Red

Terminal

36
