6
GATE SYSTEM (MASTER/SECOND SLIDE GATE)
GATE SYSTEM (COMMERCIAL SLIDE GATE)
S U G G E S T E D E N T R A P M E N T P R O T E C T I O N D E V I C E L O C A T I O N S
1-1/2" (37 mm)
1/4" (6 mm) or Larger
Depending on Loop
Wire Size
Interrupt
(Safety)
Loop
4' (1.2 m)
Typical
Seal Loops
Loop Wire Layer
12'
(3.7 m) 6' (1.8 m)
Close
Edge
Gate 2
Open
Edge
Photo Eyes for
Open Cycle
Photo Eyes for
Close Cycle
4' (1.2 m)
Typical
4' (1.2 m)
Typical
Open
Edge
Photo Eyes for
Open Cycle
Run Twisted Wire
from Loop
to Operator
STREET
COMPLEX
OR
PARKING LOT
Gate 1
Interrupt
(Safety)
Loop
Photo eye for
open cycle
Photo eye for
close cycle
8' (2.4 m)
4' (1.2 m)
Open
Edge Telephone
Entry
System
1-1/2" (37 mm)
1/4" (6 mm) or larger for Loop
wire width depending
on Loop wire size
STREET
Run twisted wire
from Loop
to Operator
Seal Loops
Loop wire
layer
Close
Edge
COMPLEX
OR
PARKING LOT
Interrupt
(Safety)
Loop
Interrupt
(Safety)
Loop
4'
(1.2 m)
Typical
4'
(1.2 m)
Typica
l
4'
(1.2 m)
Typical
