35 35
R E P A I R P A R T S - M O D E L S L 5 9 5
SERVICE KITS
ITEM PART # DESCRIPTION
K1 71-B120 Brake kit - 115 Volt models
71-B240 Brake kit - 230/460 Volt models
71-B575 Brake kit - 575 Volt models
Complete with: Brake hub kit, brake
release lever, brake disk, spring cup,
studs, compression springs, brake
solenoid, solenoid cover, spacers,
mounting plate and pressure plate.
K2 K75-18618 Disconnect kit
Complete with: Disconnect support
bracket, detent plate, disconnect lever,
release yoke bevel and disconnect
shaft.
K3 K75-12858 Clutch kit
Complete with: Clutch, pressure plate,
torque limiter sprocket assembly, bell
washer 3" ODX 1-1/2", nut 1-1/2" hex
jam, clutch disc and 1/4 X 1-1/2 key.
K4 K75-18620 Limit box kit
Complete with: Limit switch box, lid
for cover, panel, adjustment plate,
mounting bracket, limit shaft bearing,
compression spring, spacer, nut,
terminal block, RPM sensor (Hall
effect) kit, Tinnerman nut double and
e-ring.
K5 K72-18615 Drive shaft kit
Complete with: Disconnect bushing,
drive shaft, pillow block bearing,
sprocket, disconnect spring, chain,
disconnect key and e-ring.
K6 K29-32410 Alarm kit
Complete with: Alarm, spacer
and faston.
K7 K75-18493 Chain guide kit
NOT SHOWN
71-6532449 Heater kits (Optional) -
115/575V Operators
71-6532448 Heater kits (Optional) -
208/230/460V Operators
K50-18423 Replacement heater with
thermostat only
INDIVIDUAL PARTS
ITEM PART # DESCRIPTION
1 K20-1050C-2P Motor - models SL595-50-11,
SL595-50-21, SL595-50-81
K20-3050C-4P Motor - models SL595-50-23,
SL595-50-43, SL595-50-83
K20-3050M-5 Motor - model SL595-50-53
K20-1100C-2P Motor - models SL595-100-11,
SL595-100-21, SL595-100-81
K20-3100C-4P Motor - models SL595-100-23,
SL595-100-43, SL595-100-83
K20-3100M-5 Motor - model SL595-100-53
K20-3200C-5
Motor - model SL595-200-53
K20-1150C-2P Motor - models SL595-150-21,
SL595-150-11
2 32-10540 Gear reducer (20:1)
3 10-30702 Chain guard
4 11-3602 Idler shaft
5 15-3619 Sprocket 50B19 1-1/4" X 1/4"
6 305-153613 Idler sprocket
7 10-3209 Gate bracket
8 11-3503 Take-up bolt
9 19-3025 Chain #50, nickel plated - 25'
10 44-18491 Enclosure
11 82-QN43-12 Sq hd ss 7/16-14" X 3/4"
12 91-G0149 Idler bolt w/ zirc fitting
13 10-30699 Bracket mounting
14 K1C3196-3 Antenna
15 23-2016 Limit switch
16 13-10024 Limit nut
17 K74-G0589 RPM sensor (Hall effect) kit
18 12-3601 Pillowblock bearing
19 39-10541 Clutch disk
NOT SHOWN
23-34815 Stop/Reset button - located on
enclosure door
