Smart Touch Controller Menu Guide for StrongArm (HTG 320)
To gain access to the User Menu, press the Menu button when the gate is stopped. The LCD will scroll through key
several items, then stop at the close timer setting [Ct ].
User Menu Options Default Description
U1 [Ct 0] Close timer setting 0 0 = Close timer off or 1 – 99 seconds
U2 [hC 0] Momentary Close 0 0 = momentary, 1= Constant hold PB required to close gate
U3 [ho 0] Momentary Open 0 0 = momentary, 1= Constant hold PB required to open gate
U4 [AP 0] AC Power loss function 0 0 – 3 (0 =Type A, 1 = B, 2 = C, 3 = D) See handbook
U5 [ro 0] Radio control option 0 0 = Open only, 1 = Adds Close capability when fully open
U6 [bF 2] Warn before operate 0 0 = none, 1 = Buzzer alerts 3 sec before & when in motion,
2 = Buzzer alerts 3 sec before + first 2 seconds in motion
U7 [FA 0] Forced open Alert and
automatic gate reposition 0 0 = disabled, 1 sound buzzer (2 pulses/sec) if forced
open for more than four seconds, time out in 30 Sec
U8 [dA 0] Drift Closed Alert and
automatic gate reposition 0 0 = disabled, 1 sound buzzer (2 pulses/sec) if drift closed
and cannot reopen within four seconds.
U9 [PE 0] Photo Eye Align Mode 0 0= off, 1 = on (auto reset to 0 when close limit triggered)
U10 [CL 0] Clock set (24 hour type) 0 0= display, 1= set mins, 2= set hours, 3= set day, 4= month
U11 [Ld 5] LCD Contrast set 5 1 - 9 = Adjusts contrast of the display
U12 [dS 0] Data Log (New gen board only) 0 0 = Std. 1 = Extended (reset to 0 in 24 hr) (V4.xx software)
Note for U6
– The Warn before operate buzzer is an accessory device for StrongArm (HTG 320)
operator.
To access Installer Menu, press the Open & Reset buttons together while in the User Menu.
Installer Menu Options Default Description
I1 [uC 0] Set UL Usage Class 0 0 = Gate disabled, Set Class 1 through 4 use
I1a [bu 0] Choose Buzzer 0 0 = Buzzer not set, 1 = Freq 1, 2 = Freq. 2
I2
[Fd 0] Load Factory Defaults 0 0 = User Settings, 1 = Load defaults (resets entire menu)
I3 [dg 0] Set Master/Slave type 0 0 = Solo operator, 1 = Slave unit, 2 = Master unit
I4 [Ch 0] Set AC Charger or Solar 0 0 = DC + AC charger, 1 = DC + Solar charger
I5
[Fo 0] Enable Fire Dept. Open 0 0 = input disabled, 1 = enabled
I6 [oC 0] Enable Emergency close 0 0 = input disabled, 1 = enabled
I7 [SE 3] Inherent Sensor sensitivity 3 1 = Maximum sensitivity, 9 = Lowest sensitivity
I8
[SS 0] Inherent Sensor function 0 1 = stop only (note, functions in usage class 4 only)
I9 [LC 0] Leaf delay Close 0 0 = none (1-7) ½ second steps (Master/Slave only)
I10 [Lo 0] Leaf delay Open 0 0 = none (1-7) ½ second steps (Master/Slave only)
I11 [rt 0] Maximum run timer 0 0 = 60 Seconds max run, 1 = 300 Seconds max run
I12
[EC 0] PEC reverse to open 0 0 = Close eye stops only, 1 = 2 sec reverse to open
I13 [PC 0] Set PEC output – NO/NC 0 0 = Normally Open PE output, 1 = N.C. (Supervised mode)
I14 [gC 0] Set Edge input – NO/NC 0 0 = Normally Open Edge output, 1 = Normally Closed
I15
[tC 1] Time clock/ Interlock input 1 0 = select Time Clock, 1 = select Open Interlock
I15a
[dt 0] Disable Free Exit/Close Timer 0 0 = disable Free Exit, 1 = disable Close Timer
I16 [or 1] OOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I17
[ir 1] IOLD detector function 1 0 = pause closing only, 1 = enable reversing to open
I18 [Cr 1] RLD -Reset detector function 0 0 = Reopen if tripped while closing, 1 = Pause only
I19 [Cb 0] RLD -Reset detector function 0 0 = One way, 1 = Bi-directional - disables ELD if tripped first
I20
[CP 0] RLD -Reset detector function 0 0 = Std. Close, 1 = Count opens & closes after equal reset
I21 [Eb 0] ELD –Exit detector function 0 0 = Off, 1 = Enable ELD back off auto close feature
I22 [r1 0] User relay 1 option 1 0 = disabled, 1 – 24 = see relay output options page 26
I23
[r2 0] User relay 2 option 6 0 = disabled, 1 – 24 = see relay output options page 26
I24
[r3 0] User relay 3 option 1 0 = disabled, 1 – 24 = see relay output options page 26
I25 [tL 0] Gate Open alert 2 0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I26 [Lt 0] Loitering alert 3 0 = 0 sec, 1= 15s, 2= 45s, 3= 75s, 4= 105s, 5= 135s
I26a
[SA 0] System Address 0 0 = no network, 1- 99 network ―drop‖ address
I27 [ELd0] Test factory ELD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I28 [iLd0] Test factory IOLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I29
[oLd0] Test factory OOLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
I30
[rLd0] Test factory RLD 0 0=Run, 1=show freq, 2=show call level 0-7, 3= set Freq 1-4
