Description of Functions Available in the Installer Menu
Installer 15 [tC 1] Time clock / Interlock input: This menu item configures the input at terminal #7 to be
either for the gate interlock function or for an external time clock to open input. The default setting is [tC_1]
for the interlock function.
Installer 15a [dt 0] Disable Free Exit / Close timer: This input configures the input at terminal #9 to disable
either the Free Exit Detector on terminal #8, or the Timer To Close function. Default setting is [dt 0] allowing
disabling of the free exit detector.
Installer 16 [or 1] OOLD (Outside Obstruction loop detector) function: The default for this menu item is
for full reversal when the OOLD is triggered. The optional setting [or_0] causes the gate to only pause when
triggered. Closure begins as soon as the loop is clear again.
Installer 17 [ir 1] IOLD (Inside Obstruction loop detector) function: The default for this menu item is for
full reversal when the IOLD is triggered. The optional setting [ir_0] causes the gate to only pause when
triggered. Closure begins as soon as the loop is clear again.
Installer 18 [Cr 0] RLD (Reset loop detector) function: The default for this menu item allows the arm to
reopen if the reset loop detector is triggered during closure of the gate. The optional setting [Cr_1] allows the
reset loop detector, if triggered, to only pause the arm during its closure.
Installer 19 [Cb 0] RLD (Reset loop detector) function: The optional setting for this menu item allows an
RLD input to disable the free exit detector (ELD) until the gate is fully closed. This is used for bi-directional
traffic. The default function allows normal operation of the free exit detector.
Installer 20 [CP 0] RLD (Reset loop detector) function: The default for this menu item allows the reset
loop detector, when triggered and released, to close the arm immediately. The optional setting [Cp_1] allows
the Smart Touch system to remember an additional open count if the open input is activated a 2
nd
time while
the first vehicle still remains over the reset loop. This option is needed when there is an anti-pass back type
card reader to prevent a vehicle from being stranded.
Installer 21 [Eb 0] ELD (Free exit loop detector) function: The optional setting for this menu item creates
an automatic close function if a vehicle triggers, than backs off the free exit loop detector. The default
function allows normal latch open operation of the free exit detector.
Installer 22, 23, 24 [r1 0], [r2 0], [r3 0] User output relay 1 - 3 programming options: These three
menu items are used to configure the function of the three user output relays. There are 19 optional choices,
which are described in detail on page 28.
Installer 25 [t L 0] Gate Open alert: This menu item is to adjust the time delay before activating the user
relay function #8, described on page 28. Time settings up to 135 seconds.
Installer 26 [Lt 0] Loitering alert: This menu item is to adjust the time delay before activating the user
relay function #13, described on page 28. Time settings up to 135 seconds.
Installer 26a [SA 0] System Address: Set the system address for network communication. 0 = no network
communication, 1-99 set individual poling addresses. Requires v4.24 software or higher.
Installer 27 [ELd0] Factory ELD: Controls the HY-5A Free Exit loop detector, see page 41.
Installer 28 [iLd0] Factory IOLD: Controls the HY-5A IOLD loop detector, see page 41.
Installer 29 [oLd0] Factory OOLD: Controls the HY-5A OOLD loop detector, see page 41.
Installer 30 [rLd0] Factory RLD: Controls the HY-5A Reset loop detector, see page 41.
