StrongArm Installation and Reference 29
19. Flasher Relay: This output is intended to control flashing lights that pulse once per second. The relay is
activated all the time, except when the open limit switch is triggered.
20. Free Exit Loop Vehicle Detector output (available with h3.23 and higher software): This output is active
whenever the ELD is tripped.
21. Inside Obstruction Vehicle Detector output (available with h3.23 and higher software): This output may
be used to interlock to an exit device to prevent pedestrian use. This output is active whenever the IOLD is
tripped.
22. Reset Loop Vehicle Detector output (available in h3.23 and higher software): This output is active
whenever the RLD is tripped.
23. Gate Lock Output (available in h3.26 and higher software): External gate lock output. Activates at initiation
of open cycle and remains on for 10 seconds. Similar to #6 but shuts off after 10 seconds.
24. Gate at Partial Open Position (available in h3.26 and higher software): This output is active when the
partial open position is reached or exceeded.
Clock Functions
Setting the Time and Date
The Smart Touch Controller is equipped with a 24 hour (military time), 365 day clock, so that events of significance
can be logged and stamped with both the time and the date. This feature is useful to record key historical
operational data and a log of Alerts, Faults and Errors all of which can be accessed via the RS232 port. Optional
software and a serial communication cable are required in order to read this data*.
1. To set or adjust the time, go the User menu item [CL_0] and push the Select button, so that [CL_0] blinks.
Using the Previous and/or Next buttons, change the setting from [CL_0] to 1, 2, 3 or 4 depending upon
which setting is to be changed. 1 = minutes / 2 = hours / 3 = days / 4 = months.
2. Push the Select button. The display will change to a blinking (adjustable) value. Different displays will
appear (see table below) based on which [CL] value is selected:
Setting Value Display
[CL 1] minutes [ni 0 –59]
[CL 2] hours [hr 0 –23]
[CL 3] days [dA 1-31]
[CL 4] months [no 1-12]
[CL 0] Run Mode None
3. Change the hour, minute, day or month to the desired value using the Previous and/or Next buttons, then
press the Select button to enter the change. [CL 0] will appear.
4. To change another setting, Press the Select button, (display will blink), then move to that setting using the
Previous and /or Next buttons and repeat steps 2 and 3 until the clock is fully set.
5. When finished, be sure [CL 0] is displayed, then push MENU to exit.
6. A lithium disk battery supports the clock so that the time is not lost when the main power is off. This battery
should be replaced about every five years. Use a DL 2025 / DL 2032 or
CR 2025 / 2032 battery.
* S.T.A.R.T. Configuration and Diagnostic software is available for free download at www.hysecurity.com. Serial
communication cable and Serial to USB adaptor (if needed) are available through HySecurity distributors (Cable
and USB Adaptor Kit Part # MX000667)
.
