Controlled Products Systems Group 6500-083 - Manual (Page 3)

2
6500-065-E-2-08
SPECIFICATIONS 1
SECTION 1 - INSTALLATION 10
SECTION 2 - WIRING 14
Gate Construction
Important Safety Instructions
Instructions regarding intended installation:
Important Notices
UL325 Entrapment Protection
Glossary
Swing Gate Requirements
Swing Gate Protection
4
4
4
5
6
7
8
9
10
10
11
11
12
12
13
13
14
15
15
16
17
18
19
1.1 Samples of Standard Installation
1.2 Location of Gate Operator
1.3 Concrete Pad and Conduit Locations
1.4 Securing Operator to Pad
1.5 Attach Gate Bracket
1.6 Determining Arm Lengths
1.7 Installation of Warning Signs
1.8 Gates Opening Wider Than 90°
2.1 Conduit Requirements
2.2 High Voltage Wire Runs
2.3 High Voltage Terminal Connections
2.4 Control Wiring
2.5 Loop Detector Wiring
2.6 Auxiliary Device Wiring
2.7 Primary / Secondary (Dual) Gate Connection
