June, 2004
750 Operator And

455 D Control Panel Installation Manual

Figure 13. The 750 Extension Arm

Side View

Top View

750/ 760 collar

Attaches to the
bottom of the gate

Positive stops (not included)

Slides through side

channel as gate swings

Figure 12. 750 Extension Arms with Built-In Positive Stops (See

Page 38 for proper operator location when using the extension arms

with built in positive stops)

Side View

Top View

750/ 760 collar

Attaches to the
bottom of the gate

Slides through side

channel as gate swings

Extension Arm Without Stops

Positive Stops

Extension Arm With Positive Stops
