④ Fix the camera with the fixing screw.
⑤ Insert the Cable Cover into Ceiling Bracket. and fix it with the supplied fixing screw.
◎ Power Connection
- The standard power for the system is 12V DC/1A
Please, check the voltage and current capacity of rated power carefully.
Rated power is included in the back of main unit.
◎ Video Connection
- Connect with the supplied Cable. (For installation)
◎ AUDIO IN/OUT
- Connect with audio input/output device.
IPM3063N(P) Installation
11 10
Cabling
RATED POWER INPUT VOLTAGE RANGE CURRENT CONSUMPTION
12V DC 11V ~ 18V DC 1A
Relay Output
Image Output Device (for installation)
POWER
IrDA Sensor
Door Switch
Ethernet/LAN
