◎ CCD Sensor : 1/4” Interline Transfer CCD
◎ 10x Optical Zoom, 10x Digital Zoom (Max. 100x Zoom)
◎ Day & Night Function
◎ Various Focus Mode : Auto-Focus / Manual Focus / Semi-Auto Focus.
◎ Independent & Simultaneous Camera Characteristic Setup in Preset operation
◎ Support D1, CIF output resolution.
◎ MJPEG, MPEG4, H.264 codec selectable.
◎ Max. 30 frame/sec support.
◎ Support Dual Stream.
◎ Bi-direction audio support (ADPCM, G.726)
◎ Up to 10 users can be connected.
◎ Support protocols : IPv4, HTTP, TCP, RTSP, UDP, SMTP, FTP, ICMP, DHCP, UPnP,
Bonjour, ARP, DNS, DynDNS.
◎ Support Motion Detection (Up to 3 motion detection area can be defined).
◎ When event occurred, image save function (JPEG file, Internal memory, SD Card).
◎ Max. 360°/sec high speed Pan/Tilt Movement.
◎ Using Vector Drive Technology, Pan/Tilt motions are accomplished in a shortest path.
As a result, time to target view is reduced dramatically and the video on the monitor is
very natural to watch.
◎ For jog operation using screen jog, since ultra slow speed 0.05°/sec can be reached,
it is very easy to locate camera to desired target view. Additionally it is easy to move
camera to a desired position with zoom-proportional pan/tilt movement.
◎ Max. 127 Presets are assignable and characteristics of each preset can be set up
independently, such as White Balance, Auto Exposure, Label and so on.
◎ Max. 8 set of Swing action can be stored. This enables to move camera repetitively
between two preset positions with designated speed.
◎ Max. 4 of Patterns can be recorded and played back.
◎ Max. 8 set of Group action can be stored. This enables to move camera repetitively
with combination of Preset or Pattern or Swing. A Group is composed of max. 20
entities of Preset/Pattern/Swings.
◎ Privacy Masks are assignable, not to intrude on other’s privacy. (4 Privacy Zones)
◎ OSD menu is provided to display the status of camera and to configure the functions
interactively.
◎ The information such as Camera ID, Pan/Tilt Angle, Iris, Alarm Input and Preset can
be displayed on screen.
◎ 4 alarm sensor Inputs and 1 alarm output relay are available.
◎ To reject external electric noise and shock perfectly, alarm sensor Input is decoupled
with photo coupler.
◎ To reject external electric noise and shock perfectly, alarm sensor Input is decoupled
with photo coupler.
◎ The signal range of sensor input is from DC 5.0 to 12.0 volts to adopt various
applications.
◎ Relay output is able to connect. (max. 125V AC/0.5A or 24V DC/1A)
◎ If an external sensor is activated, camera can be set to move to the corresponding
Preset position.
Camera Specifications
Network Specifications
Alarm In/Out Functions
Preset, Pattern, Swing, Group, Privacy Mask ..
OSD(On Screen Display) Menu
7 6
Powerful Pan/Tilt Functions
