5 Technical Data
5.1 BS210 Base Station Specifications
GENERAL
Channels:
2 audio channels
Frequency Range:
2400 – 2483.5 MHz
Frequency Response:
200 Hz to 3.5 kHz
Power Requirements:
100-240VAC, 50-60Hz or 12-14VDC
Temperature Range:
32-122°F (0-50°C)
Size:
19” x 1.72” x 17.13” (1-RU) (48.26 x 4.37 x 43.51 cm)
Weight:
9.0 lbs. (4.1 kg) maximum
# of COMMUNICATOR
®
s
per Base:
15 can be registered.
In single-channel operation, 4 can have simultaneous full-duplex communication.
In dual-channel operation, 3 can have simultaneous full-duplex communication.
4-Wire I/O:
RJ45, 600Ω balanced, level adjustable, simultaneous operation with 2-wire
2-Wire I/O:
XLR-3M, XLR-3F, externally-switchable RTS
®
or Clear-Com
®
mode,
200Ω, level adjustable, null adjustable to 50dB attentuation, typical
Auxiliary Input:
XLR-3F/¼” (6.35 mm) combo jack, 600Ω balanced, level adjustable
Auxiliary Output:
XLR-3M, 600Ω balanced, level adjustable
Headset Connector:
4-pin mini-DIN, Electret microphone
Headset Output:
200mW into 32Ω
Antenna Type:
External ½ -wave dipole (R-TNC connector), RX/TX horizontal/vertical diversity
System Distortion:
<2%
Communication Security: 64-bit encryption, dual-slot diversity
BASE STATION TRANSMITTER
Type:
Frequency Hopping, Spread Spectrum (FHSS)
Transmit Power:
100mW burst
Modulation Type:
Gaussian filtered FSK, TDMA
Frequency Stability:
13 ppm
Harmonics/Spurious:
Exceeds FCC and ETSI specifications over temperature
BASE STATION RECEIVER
Type: RF Sensitivity:
Frequency Hopping, Spread Spectrum <-90dBm w 10-3 BER
Frequency Stability:
13 ppm
Distortion:
<2%
